Unboxing S3 Object Lambda

Amazon S3 Object Lambda offers a way to execute a Lambda function when someone wants to download a file (GetObject) from an S3 bucket. You can implement whatever logic you wish and return any data as the response via the WriteGetObjectResponse API. Keep in mind that the Lambda function must finish within 60 seconds and is called synchronously.

How S3 Object Lambda works

The following figure shows the needed components:

Let’s look at the parts more closely:

S3 Object Lamda Access Point: References your Lambda function and your S3 Access Point. Block Public Access is always enabled.
Lambda function: Invoked when a GetObject request is made to the S3 Object Lambda Access Point.
S3 Access Point: Takes care of the non GetObject requests (such as ListObjects) and serves the pre-signed URL of the original file passed into the Lambda function.
S3 Bucket: Stores the original file (in fact, the original file could be non-existent).

In the following video, I go into more details and share code with you:

Introducing S3 Object Lambda
Use Cases
Demo: Generating content
Understanding Pricing
Pitfall: Keep the Lambda function running

Pricing

You pay for the following:

S3 Get Object API (as usual)
Lambda invocation
Lambda GB-second
$0.005 per GB returned via WriteGetObjectResponse

Source Code

---
AWSTemplateFormatVersion: '2010-09-09'
Description: 'S3 Object Lambda Demo'
Resources:
  Bucket:
    Type: 'AWS::S3::Bucket'
    Properties: {}
  FunctionLogGroup:
    Type: 'AWS::Logs::LogGroup'
    Properties:
      LogGroupName: !Sub '/aws/lambda/${Function}'
      RetentionInDays: 14
  FunctionRole:
    Type: 'AWS::IAM::Role'
    Properties:
      AssumeRolePolicyDocument:
        Version: '2012-10-17'
        Statement:
        - Effect: Allow
          Principal:
            Service: 'lambda.amazonaws.com'
          Action: 'sts:AssumeRole'
      Policies:
      - PolicyName: 's3-object-lambda'
        PolicyDocument:
          Statement:
          - Effect: Allow
            Action: 's3-object-lambda:WriteGetObjectResponse'
            Resource: '*'
  FunctionPolicy:
    Type: 'AWS::IAM::Policy'
    Properties:
      Roles:
      - !Ref FunctionRole
      PolicyName: lambda
      PolicyDocument:
        Statement:
        - Effect: Allow
          Action:
          - 'logs:CreateLogStream'
          - 'logs:PutLogEvents'
          Resource: !GetAtt 'FunctionLogGroup.Arn'
  Function:
    Type: 'AWS::Lambda::Function'
    Properties:
      Code:
        ZipFile: |
          const AWS = require('aws-sdk');
          const s3 = new AWS.S3({apiVersion: '2006-03-01'});
          exports.handler = async (event) => {
              console.log(JSON.stringify(event));
              await s3.writeGetObjectResponse({
                RequestRoute: event.getObjectContext.outputRoute,
                RequestToken: event.getObjectContext.outputToken,
                Body: 'hello'
              }).promise()
              return {};
          };
      Handler: 'index.handler'
      MemorySize: 128
      Role: !GetAtt 'FunctionRole.Arn'
      Runtime: 'nodejs12.x'
      Timeout: 60
  AccessPoint:
    Type: 'AWS::S3::AccessPoint'
    Properties:
      Bucket: !Ref Bucket
  LambdaAccessPoint:
    Type: 'AWS::S3ObjectLambda::AccessPoint'
    Properties:
      Name: !Ref 'AWS::StackName'
      ObjectLambdaConfiguration:
        SupportingAccessPoint: !Sub 'arn:${AWS::Partition}:s3:${AWS::Region}:${AWS::AccountId}:accesspoint/${AccessPoint}'
        TransformationConfigurations:
        - Actions:
          - GetObject
          ContentTransformation:
            AwsLambda:
              FunctionArn: !GetAtt 'Function.Arn'
Outputs:
  BucketName:
    Value: !Ref Bucket
  LambdaAccessPointArn:
    Value: !GetAtt 'LambdaAccessPoint.Arn'

To invoke the S3 Object Lambda Access Point, run with your ARN: aws s3api get-object --bucket arn:aws:s3-object-lambda:us-east-1:123456789123:accesspoint/s3-object-lambda --key file.txt outfile.txt
