Unboxing AWS DataSync

Your toolbox should contain AWS DataSync, a service to synchronize data between all kinds of locations. Copy data between S3, EFS, and FSx. On top of that, DataSync works with on-premises locations like NFS, SMB, and more.

[wpcc-element _tag=”source” type=”image/webp” srcset=”/images/2020/12/move@730w.webp 730w, /images/2020/12/move@730w2x.webp 1460w, /images/2020/12/move@610w.webp 610w, /images/2020/12/move@610w2x.webp 1220w, /images/2020/12/move@450w.webp 450w, /images/2020/12/move@450w2x.webp 900w, /images/2020/12/move@330w.webp 330w, /images/2020/12/move@330w2x.webp 660w, /images/2020/12/move@545w.webp 545w, /images/2020/12/move@545w2x.webp 1090w” sizes=”(min-width: 1200px) 730px, (min-width: 992px) 610px, (min-width: 768px) 450px, (min-width: 576px) 330px, 545px” _close=”0″]

In this week’s video Andreas unboxes AWS DataSync for you, explains the core concepts, and demos how to copy data between S3 and EFS.

[wpcc-iframe class=”embed-responsive-item lozad” data-src=”https://www.youtube-nocookie.com/embed/-ru39l6qljk” allow=”accelerometer; autoplay; clipboard-write; encrypted-media; gyroscope; picture-in-picture” allowfullscreen=””]

Here is the Terraform configuration code, that we used for our example to synchronize data between S3 and EFS. The Terraform configuration creates the following resources:

S3 bucket
EFS file system
DataSync configuration
EC2 instance allowing you to access the EFS file system
Security Groups for DataSync and EC2
IAM roles for Data Sync and EC2

Use the AWS Systems Manager Session Manager to connect with the EC2 instance to mount and inspect the EFS file system.

terraform {
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "~> 3.0"
    }
  }
}

provider "aws" {
  region = "eu-west-1"
}

data "aws_vpc" "default" {
  default = true
}

data "aws_subnet_ids" "public" {
  vpc_id = data.aws_vpc.default.id
}

data "aws_subnet" "selected" {
  vpc_id = data.aws_vpc.default.id
  id = sort(data.aws_subnet_ids.public.ids)[0]
}

data "aws_ami" "amzn2" {
  most_recent = true

  filter {
    name   = "name"
    values = ["amzn2-ami-hvm-2.0.*-x86_64-gp2"]
  }

  filter {
    name   = "virtualization-type"
    values = ["hvm"]
  }

  owners = ["137112412989"]
}

resource "aws_datasync_location_s3" "demo" {
  s3_bucket_arn = aws_s3_bucket.demo.arn
  subdirectory = "/"

  s3_config {
    bucket_access_role_arn = aws_iam_role.datasync.arn
  }
}

resource "aws_datasync_location_efs" "demo" {
  efs_file_system_arn = aws_efs_file_system.demo.arn

  ec2_config {
    security_group_arns = [ aws_security_group.datasync.arn ]
    subnet_arn = data.aws_subnet.selected.arn
  }
}

resource "aws_datasync_task" "demo" {
  name = "demo-s3-to-efs"
  source_location_arn = aws_datasync_location_s3.demo.arn
  destination_location_arn = aws_datasync_location_efs.demo.arn
}


resource "aws_s3_bucket" "demo" {
  bucket_prefix = "demo-"
}

resource "aws_efs_file_system" "demo" {
  tags = {
    Name = "Demo"
  }
}

resource "aws_iam_role" "datasync" {
  name = "demo-datasync"

  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect = "Allow"
        Principal = {
            Service = "datasync.amazonaws.com"
        }
        Action = "sts:AssumeRole"
      },
    ]
  })
}

resource "aws_iam_role_policy" "datasync" {
  role = aws_iam_role.datasync.name

  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect = "Allow"
        Action = [
          "s3:GetBucketLocation",
          "s3:ListBucket",
          "s3:ListBucketMultipartUploads",
          "s3:HeadBucket"
        ]
        Resource = aws_s3_bucket.demo.arn
      },
      {
        Effect = "Allow"
        Action = [
          "s3:AbortMultipartUpload",
          "s3:DeleteObject",
          "s3:GetObject",
          "s3:ListMultipartUploadParts",
          "s3:GetObjectTagging",
          "s3:PutObjectTagging",
          "s3:PutObject"
        ]
        Resource = "${aws_s3_bucket.demo.arn}/*"
      }
    ]
  })
}

resource "aws_efs_mount_target" "demo" {
  for_each      = data.aws_subnet_ids.public.ids
  file_system_id = aws_efs_file_system.demo.id
  subnet_id      = each.value
  security_groups = [ aws_security_group.efs.id ]
}

resource "aws_security_group" "efs" {
    name_prefix = "demo-efs-"
    vpc_id = data.aws_vpc.default.id
}

resource "aws_security_group_rule" "efs_datasync" {
  type              = "ingress"
  from_port         = 2049
  to_port           = 2049
  protocol          = "tcp"
  security_group_id = aws_security_group.efs.id
  source_security_group_id = aws_security_group.datasync.id
}

resource "aws_security_group_rule" "efs_ec2" {
  type              = "ingress"
  from_port         = 2049
  to_port           = 2049
  protocol          = "tcp"
  security_group_id = aws_security_group.efs.id
  source_security_group_id = aws_security_group.ec2.id
}

resource "aws_security_group" "datasync" {
    name_prefix = "demo-datasync-"
    vpc_id = data.aws_vpc.default.id
}

resource "aws_security_group_rule" "datasync" {
  type              = "egress"
  from_port         = 2049
  to_port           = 2049
  protocol          = "tcp"
  security_group_id = aws_security_group.datasync.id
  source_security_group_id = aws_security_group.efs.id
}

resource "aws_instance" "demo" {
  ami           = data.aws_ami.amzn2.id
  instance_type = "t3.micro"
  vpc_security_group_ids = [ aws_security_group.ec2.id ]
  subnet_id = data.aws_subnet.selected.id
  iam_instance_profile = aws_iam_instance_profile.ec2.name

  tags = {
    Name = "demo-datasync"
  }
}

resource "aws_security_group" "ec2" {
    name_prefix = "demo-ec2-"
    vpc_id = data.aws_vpc.default.id

    egress {
      from_port   = 0
      to_port     = 0
      protocol    = "-1"
      cidr_blocks = ["0.0.0.0/0"]
    }
}

resource "aws_iam_role" "ec2" {
  name = "demo-ec2"

  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect = "Allow"
        Principal = {
          Service = "ec2.amazonaws.com"
        }
        Action = "sts:AssumeRole"
      },
    ]
  })
}

resource "aws_iam_instance_profile" "ec2" {
  name = "demo-ec2"
  role = aws_iam_role.ec2.name
}

resource "aws_iam_role_policy" "ec2" {
  role = aws_iam_role.ec2.name

  policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Effect = "Allow"
        Action = [
          "ec2messages:*",
          "ssmmessages:*",
          "ssm:UpdateInstanceInformation",
          "ssm:GetDeployablePatchSnapshotForInstance",
          "ssm:ListAssociations"
        ]
        Resource = "*"
      }
    ]
  })
}
