How to secure your DevOps tools with ALB Authentication?
06
Aug

Are you hosting any DevOps tools like GitLab, Jenkins, Kibana, Grafana, or phpMyAdmin yourself? On the one hand, it is convenient to provide access to those tools via the Internet. On the other hand, those tools add high-risk attack vectors to your infrastructure. Therefore, I recommend securing your DevOps tools by adding an extra layer of security: authentication provided by the Application Load Balancer (ALB).

[wpcc-element _tag=”source” type=”image/webp” srcset=”/images/2020/01/lock@730w.webp 730w, /images/2020/01/lock@730w2x.webp 1460w, /images/2020/01/lock@610w.webp 610w, /images/2020/01/lock@610w2x.webp 1220w, /images/2020/01/lock@450w.webp 450w, /images/2020/01/lock@450w2x.webp 900w, /images/2020/01/lock@330w.webp 330w, /images/2020/01/lock@330w2x.webp 660w, /images/2020/01/lock@545w.webp 545w, /images/2020/01/lock@545w2x.webp 1090w” sizes=”(min-width: 1200px) 730px, (min-width: 992px) 610px, (min-width: 768px) 450px, (min-width: 576px) 330px, 545px” _close=”0″]

Use the ALB to make sure incoming requests are authenticated before they are forwarded to one of your DevOps tools. Right now, the ALB supports two authentication methods:

  • Cognito User Pool comes with a built-in user database and supports user federation (Google, Facebook, SAML, OICD, …) as well.
  • OpenID Connect (OICD) integrates with any OICD-compliant identity provider.

In short, the process works as follows:

  1. The engineer accesses Grafana by pointing the browser to https://grafana.example.com.
  2. The ALB redirects the engineer to the login page provided by AWS Cognito User Pool.
  3. The engineer authenticates with username, password, and optionally a one-time-password.
  4. AWS Cognito User Pool redirects the engineer to https://grafana.example.com.
  5. The ALB verifies the authentication information and forwards the request to one of the targets running Grafana.

[wpcc-element _tag=”source” type=”image/webp” srcset=”/images/2020/01/alb-authentication@730w.webp 730w, /images/2020/01/alb-authentication@730w2x.webp 1460w, /images/2020/01/alb-authentication@610w.webp 610w, /images/2020/01/alb-authentication@610w2x.webp 1220w, /images/2020/01/alb-authentication@450w.webp 450w, /images/2020/01/alb-authentication@450w2x.webp 900w, /images/2020/01/alb-authentication@330w.webp 330w, /images/2020/01/alb-authentication@330w2x.webp 660w, /images/2020/01/alb-authentication@545w.webp 545w, /images/2020/01/alb-authentication@545w2x.webp 1090w” sizes=”(min-width: 1200px) 730px, (min-width: 992px) 610px, (min-width: 768px) 450px, (min-width: 576px) 330px, 545px” _close=”0″]

In the following, you will learn how to add ALB authentication to protect your DevOps tools from all kinds of attacks. The implementations are intended for small organizations.

Requirements

Before you start, make sure the following requirements are met.

  • A custom domain name pointing to your DevOps tool (e.g., grafana.example.com).
  • A valid SSL certificate (e.g., Amazon Certificate Manager) for the custom domain name.

Example: Cognito User Pool

The following CloudFormation template shows how to configure an ALB to authenticate incoming requests against a Cognito User Pool. The Cognito User Pool provides a separate user database for your DevOps tools. Check out the # inline comments for details.

---
AWSTemplateFormatVersion: '2010-09-09'
Description: 'ALB Authentication | Cognito | cloudonaut.io'
Parameters:
  VpcId:
    Type: 'AWS::EC2::VPC::Id'
  SubnetIds:
    Type: 'List<AWS::EC2::Subnet::Id>'
  PublicDomainName:
    Type: 'String' # the custom domain name (e.g., grafana.example.com)
  CertificateArn:
    Type: 'String' # the ARN of a ACM certificate valid for the custom domain name
Resources:
  LoadBalancerSecurityGroup: # Security Group for Load Balancer allows incoming HTTPS requests
    Type: 'AWS::EC2::SecurityGroup'
    Properties:
      GroupDescription: 'Load Balancer'
      VpcId: !Ref VpcId
      SecurityGroupIngress:
      - IpProtocol: tcp
        FromPort: 443
        ToPort: 443
        CidrIp: '0.0.0.0/0'
  LoadBalancer:
    Type: 'AWS::ElasticLoadBalancingV2::LoadBalancer'
    Properties:
      SecurityGroups:
      - !Ref LoadBalancerSecurityGroup
      Subnets: !Ref SubnetIds
      Type: application
  Listener:
    Type: 'AWS::ElasticLoadBalancingV2::Listener'
    Properties:
      Certificates:
      - CertificateArn: !Ref CertificateArn
      DefaultActions: # 1. Authenticate against Cognito User Pool
      - Type: 'authenticate-cognito'
        AuthenticateCognitoConfig:
          OnUnauthenticatedRequest: 'authenticate' # Redirect unauthenticated clients to Cognito login page
          Scope: 'openid'
          UserPoolArn: !GetAtt 'UserPool.Arn'
          UserPoolClientId: !Ref UserPoolClient
          UserPoolDomain: !Ref UserPoolDomain
        Order: 1
      - Type: forward # 2. Forward request to target group (e.g., EC2 instances)
        TargetGroupArn: !Ref TargetGroup
        Order: 2
      LoadBalancerArn: !Ref LoadBalancer
      Port: 443
      Protocol: 'HTTPS'
  TargetGroup:
    Type: 'AWS::ElasticLoadBalancingV2::TargetGroup'
    Properties:
      Port: 80
      Protocol: HTTP
      TargetType: ip
      VpcId: !Ref VpcId
  UserPool:
    Type: 'AWS::Cognito::UserPool'
    Properties:
      AdminCreateUserConfig:
        AllowAdminCreateUserOnly: true # Disable self-registration
        InviteMessageTemplate:
          EmailSubject: !Sub '${AWS::StackName}: temporary password'
          EmailMessage: 'Use the username {username} and the temporary password {####} to log in for the first time.'
          SMSMessage: 'Use the username {username} and the temporary password {####} to log in for the first time.'
      AutoVerifiedAttributes:
      - email
      UsernameAttributes:
      - email
      Policies:
        PasswordPolicy:
          MinimumLength: 16
          RequireLowercase: false
          RequireNumbers: false
          RequireSymbols: false
          RequireUppercase: false
          TemporaryPasswordValidityDays: 21
  UserPoolDomain: # Provides Cognito Login Page
    Type: 'AWS::Cognito::UserPoolDomain'
    Properties:
      UserPoolId: !Ref UserPool
      Domain: !Select [2, !Split ['/', !Ref 'AWS::StackId']] # Generates a unique domain name
  UserPoolClient:
    Type: 'AWS::Cognito::UserPoolClient'
    Properties:
      AllowedOAuthFlows:
      - code # Required for ALB authentication
      AllowedOAuthFlowsUserPoolClient: true # Required for ALB authentication
      AllowedOAuthScopes:
      - email
      - openid
      - profile
      - aws.cognito.signin.user.admin
      CallbackURLs:
      - !Sub https://${PublicDomainName}/oauth2/idpresponse # Redirects to the ALB
      GenerateSecret: true
      SupportedIdentityProviders: # Optional: add providers for identity federation
      - COGNITO
      UserPoolId: !Ref UserPool

What else is needed?

  1. Create a CNAME/Alias record for your custom domain name (e.g., grafana.example.com) pointing to the ALB’s DNS name (e.g., cloud-LoadB-MTNUUM0SEVMO-1111111111.eu-west-1.elb.amazonaws.com).
  2. Open the AWS Management Console and add a user to the Cognito User Pool created by CloudFormation.
  3. Browse to your custom domain name (e.g., grafana.example.com).
  4. Log in with the user you created in the penultimate step.

[wpcc-element _tag=”source” type=”image/webp” srcset=”/images/2020/01/login-cognito@730w.webp 730w, /images/2020/01/login-cognito@730w2x.webp 1460w, /images/2020/01/login-cognito@610w.webp 610w, /images/2020/01/login-cognito@610w2x.webp 1220w, /images/2020/01/login-cognito@450w.webp 450w, /images/2020/01/login-cognito@450w2x.webp 900w, /images/2020/01/login-cognito@330w.webp 330w, /images/2020/01/login-cognito@330w2x.webp 660w, /images/2020/01/login-cognito@545w.webp 545w, /images/2020/01/login-cognito@545w2x.webp 1090w” sizes=”(min-width: 1200px) 730px, (min-width: 992px) 610px, (min-width: 768px) 450px, (min-width: 576px) 330px, 545px” _close=”0″]

By the way, it is possible to create users with CloudFormation as well. Alternatively, you might want to use an existing user database. One option to do so is OpenID Connect, which you will learn about next.

Example: OpenID Connect (OICD) with Google

The following CloudFormation template shows how to configure an ALB use Google user accounts to authenticate incoming requests. Check out the # inline comments for details.

Before you proceed, you need to configure the OAuth consent screen of your application and create an OAuth Client. Open the Google API Console to do so.

Warning Choose user type Internal when configuring the OAuth consent screen. By doing so, only G Suite users within your organization are allowed to log in. When choosing External anyone with a Google account can log in.

---
AWSTemplateFormatVersion: '2010-09-09'
Description: 'ALB Authentication | Google OICD | cloudonaut.io'
Parameters:
  VpcId:
    Type: 'AWS::EC2::VPC::Id'
  SubnetIds:
    Type: 'List<AWS::EC2::Subnet::Id>'
  CertificateArn:
    Type: 'String'
  GoogleClientId:
    Type: 'String' # The OAuth Client ID from the Google API Console
  GoogleClientSecret:
    Type: 'String' # The OAuth Client Secret from the Google API Console
    NoEcho: true
Resources:
  LoadBalancerSecurityGroup:
    Type: 'AWS::EC2::SecurityGroup'
    Properties:
      GroupDescription: 'Load Balancer'
      VpcId: !Ref VpcId
      SecurityGroupIngress:
      - IpProtocol: tcp
        FromPort: 443
        ToPort: 443
        CidrIp: '0.0.0.0/0'
  LoadBalancer:
    Type: 'AWS::ElasticLoadBalancingV2::LoadBalancer'
    Properties:
      SecurityGroups:
      - !Ref LoadBalancerSecurityGroup
      Subnets: !Ref SubnetIds
      Type: application
  Listener:
    Type: 'AWS::ElasticLoadBalancingV2::Listener'
    Properties:
      Certificates:
      - CertificateArn: !Ref CertificateArn
      DefaultActions:
      - Type: 'authenticate-oidc' # 1. Authenticate with OICD
        AuthenticateOidcConfig:
          OnUnauthenticatedRequest: 'authenticate'
          Issuer: 'https://accounts.google.com'
          AuthorizationEndpoint: 'https://accounts.google.com/o/oauth2/v2/auth'
          TokenEndpoint: 'https://oauth2.googleapis.com/token'
          UserInfoEndpoint: 'https://openidconnect.googleapis.com/v1/userinfo'
          ClientId: !Ref GoogleClientId
          ClientSecret: !Ref GoogleClientSecret
        Order: 1
      - Type: forward # 2. Forward request to target group (e.g., EC2 instances)
        TargetGroupArn: !Ref TargetGroup
        Order: 2
      LoadBalancerArn: !Ref LoadBalancer
      Port: 443
      Protocol: 'HTTPS'
  TargetGroup:
    Type: 'AWS::ElasticLoadBalancingV2::TargetGroup'
    Properties:
      Port: 80
      Protocol: HTTP
      TargetType: ip
      VpcId: !Ref VpcId

What else is needed?

  1. Create a CNAME/Alias record for your custom domain name (e.g., grafana.example.com) pointing to the ALB’s DNS name (e.g., cloud-LoadB-MTNUUM0SEVMO-1111111111.eu-west-1.elb.amazonaws.com).
  2. Browse to your custom domain name (e.g., grafana.example.com).
  3. Log in with your Google account.

[wpcc-element _tag=”source” type=”image/webp” srcset=”/images/2020/01/login-google@730w.webp 730w, /images/2020/01/login-google@730w2x.webp 1460w, /images/2020/01/login-google@610w.webp 610w, /images/2020/01/login-google@610w2x.webp 1220w, /images/2020/01/login-google@450w.webp 450w, /images/2020/01/login-google@450w2x.webp 900w, /images/2020/01/login-google@330w.webp 330w, /images/2020/01/login-google@330w2x.webp 660w, /images/2020/01/login-google@545w.webp 545w, /images/2020/01/login-google@545w2x.webp 1090w” sizes=”(min-width: 1200px) 730px, (min-width: 992px) 610px, (min-width: 768px) 450px, (min-width: 576px) 330px, 545px” _close=”0″]

See Google Identity Platform: Guides: OpenID Connect to learn more.

What is next?

Be aware that the ALB only handles authentication. Anyone with a user account can log in and access your DevOps tools. The ALB does not offer additional authorization. Make sure you understand which users can log in when configuring an OpenID Connect provider. It might be anyone with a user account. Or only user accounts that belong to your organization (see the warning for OpenID Connect (OICD) with Google).

By default, your DevOps tool will not integrate with the ALB authentication. However, the ALB adds headers with the user information to all forwarded requests (e.g., x-amzn-oidc-identity contains the user name of the authenticated user). You might be able to configure your DevOps tool to use these headers for authentication and authorization. See Authenticate Users Using an Application Load Balancer to learn more.

Summary

Use authentication on the load balancer to add another layer of security to your DevOps tools like GitLab, Jenkins, Kibana, Grafana, or phpMyAdmin. Doing so reduced the attack surface to your infrastructure. Implementing ALB authentication for small organizations is quite simple by using either Cognito User Pools or Google via OpenID Connect.
