How to dockerize your Node.js Express application for AWS Fargate?

Dockerize your Node.js application for AWS Fargate

My first project with Node.js – an asynchronous event-driven JavaScript runtime, designed to build scalable network applications – was building an online trading platform in 2013. Since then, Node.js is one of my favorite technologies. I will show you how to dockerize your Node.js application based on Express – a fast, unopinionated, minimalist web framework – and run it on AWS Fargate in this blog bost. I like AWS Fargate because running containers in the cloud were never easier.

Read on to learn how to build a Docker image for a Node.js application.

Building the Docker image

The Dockerfile is based on the official Node.js Docker Image: node:10.16.2-stretch. Static files (folders img and css) are served by Express as well as the dynamic parts. The following details are required to understand the Dockerfile:

  • envsubst is used to generate the config file from environment variables
  • npm ci --only=production installs the dependencies declared in package.json (package-lock.json, to be more precise)
  • The Express application listens on port 8080
  • The Express application’s entry point is server.js and can be started with node server.js

A simple server.js file follows. Yours likely is more complicated.

server.js
const express = require('express');

const app = express();
app.use('/css', express.static('css'));
app.use('/img', express.static('img'));

app.get('/health-check', (req, res, next) => {
res.sendStatus(200);
});

app.listen(8080, '0.0.0.0');

Customization Most likely, your folder structure is different. Therefore, adapt the Copy config files and Copy Node.js files section in the following Dockerfile to your needs.

docker/Dockerfile
FROM node:10.16.2-stretch

WORKDIR /usr/src/app

ENV NODE_ENV production

# Install envsubst
RUN apt-get update && apt-get install -y gettext
COPY docker/custom-entrypoint /usr/local/bin/
RUN chmod u+x /usr/local/bin/custom-entrypoint
ENTRYPOINT ["custom-entrypoint"]
RUN mkdir /usr/src/app/config/

# Copy config files
COPY config/*.tmp /tmp/config/

# Install Node.js dependencies
COPY package*.json /usr/src/app/
RUN npm ci --only=production

# Copy Node.js files
COPY css /usr/src/app/css
COPY img /usr/src/app/img
COPY views /usr/src/app/views
COPY server.js /usr/src/app/

# Expose port 8080 and start Node.js server
EXPOSE 8080
CMD ["node", "server.js"]

The custom entrypoint is used to generate the config file from environment variables with envsubst.

docker/custom-entrypoint
#!/bin/bash
set -e

echo "generating configuration files"
FILES=/tmp/config/*
for f in $FILES
do
c=$(basename $f .tmp)
echo "... $c"
envsubst < $f > /usr/src/app/config/${c}
done

echo "starting $@"
exec "$@"

Next, you will learn how to test your containers and application locally.

Testing locally

Use Docker Compose to run your application locally. The following docker-compose.yml file configures Docker Compose and starts two containers: Node.js and a MySQL database.

docker/docker-compose.yml
version: '3'
services:
nodejs:
build:
context: '..'
dockerfile: 'docker/Dockerfile'
ports:
- '8080:8080'
depends_on:
- mysql
environment:
DATABASE_HOST: mysql
DATABASE_NAME: app
DATABASE_USER: app
DATABASE_PASSWORD: secret
mysql:
image: 'mysql:5.6'
command: '--default-authentication-plugin=mysql_native_password'
ports:
- '3306:3306'
environment:
MYSQL_ROOT_PASSWORD: secret
MYSQL_DATABASE: app
MYSQL_USER: app
MYSQL_PASSWORD: secret

The following command starts the application:

docker-compose -f docker/docker-compose.yml up --build

Magically, Docker Compose will spin up two containers: Node.js and MySQL. Point your browser to http://localhost:8080 to check that your web application is up and running. The log files of all containers will show up in your terminal, which simplifies debugging a lot.

After you have verified that your application is working correctly, cancel the running docker-compose process by pressing CTRL + C, and tear down the containers:

docker-compose -f docker/docker-compose.yml down

Deploying on AWS

You are now ready to deploy your application on AWS.

(1) Build Docker image:

docker build -t nodejs-express:latest -f docker/Dockerfile .

(2) Create ECR repository:

aws ecr create-repository --repository-name nodejs-express
--query 'repository.repositoryUri' --output text

(3) Login to Docker registry (ECR):

$(aws ecr get-login --no-include-email)

(4) Tag Docker image:

docker tag nodejs-express:latest
111111111111.dkr.ecr.eu-west-1.amazonaws.com/
nodejs-express:latest

(5) Push Docker image:

docker push
111111111111.dkr.ecr.eu-west-1.amazonaws.com/
nodejs-express:latest

There is only one step missing: you need to spin up the cloud infrastructure.

  1. Use our Free Templates for AWS CloudFormation.
  2. Use our cfn-modules.
